型 號

Type

流量

Flow

(L/min)

揚程

Head

(m)

出口壓力

Discharge

Pressure

(bar)

 吸程

Sucked

Lift

(m)

允許通過

顆粒直徑

Max Grain

Diameter

(mm)

空氣消耗量

Max Air

Consumption

(scfm)

進氣口徑

Compressed air inlet

(inch)

進出口尺寸

Inlet and Outlet

(mm)

絲扣

Threaded

法蘭

Flanged

QBY3-10

0~18.9

0~70

7

2.5-3

≤1.5

≤9

1/4

10

QBY3-15

0~18.9

0~70

7

2.5-3

≤1.5

≤9

1/4

15

QBY3-20

0~57

0~70

7

4.5-7.6

≤2.5

≤28

1/4

20

QBY3-25

0~57

0~70

7

4.5-7.6

≤2.5

≤28

1/4

25

QBY3-25A

0~151

0~84

8.4

5.4

≤3.2

≤60

1/2

25

QBY3-32

0~151

0~84

8.4

5.4

≤3.2

≤60

1/2

32

QBY3-40

0~151

0~84

8.4

5.4

≤3.2

≤60

1/2

40

QBY3-50

0~378.5

0~84

8.4

5.48

≤5.5

≤125

1/2

50

QBY3-65

0~378.5

0~84

8.4

5.48

≤5.5

≤125

1/2

65

QBY3-80

0~568

0~84

8.4

5.48

≤6.3

≤175

1/2

80

QBY3-100

0~568

0~84

8.4

5.48

≤6.3

≤175

1/2

100

QBY3-125

0~1041

0~84

8.4

2.4-7.6

≤10

≤325

3/4

125

注：以上性能參數為清水測試參數          單位換算：1L/min=0.06m3/h=0.03531scfm  |  1bar=0.1MPa

型號

可選泵體材質

Available Material of Pump Body

可選隔膜材質

Available Material of Diaphragm

鑄鐵

Cast Iron

鑄鋼

Cast

Steel

鋁

合金

AL Alloy

增強

聚丙烯

RPP

不銹鋼

Stainless

Steel

全氟

塑料

PVDF

襯氟

Fluorin

Lining

聚醚

彈性體

Hytrel

丁腈

橡膠

NBR

氯丁

橡膠

Neoprene

聚四氟乙烯

PTFE

聚全氟乙烯

FEP

QBY3-10

●

●

●

●

●

●

●

●

●

QBY3-15

●

●

●

●

●

●

●

●

●

QBY3-20

●

●

●

●

●

●

●

●

●

●

QBY3-25

●

●

●

●

●

●

●

●

●

●

QBY3-25A

●

●

●

●

●

●

●

●

●

●

QBY3-32

●

●

●

●

●

●

●

●

●

●

QBY3-40

●

●

●

●

●

●

●

●

●

●

QBY3-50

●

●

●

●

●

●

●

●

●

●

●

QBY3-65

●

●

●

●

●

●

●

●

●

●

●

QBY3-80

●

●

●

●

●

●

●

●

●

●

QBY3-100

●

●

●

●

●

●

●

●

●

●

QBY3-125

●

●

●

●

●

●

●

●

●

PTFE=F4，FEP=F46  |  PP和PVDF材質只有配FEP膜片
